Pulse-1
GPS TRACKING DEVICEPLS-01
DEPLOY & FORGET

Pulse-1

FROM$449
Request Quote
3+YEARS
Battery life
1SEC
Min interval
PERM
Binding
ALWAYSON
Geofence
01 — Overview

Intelligence-grade
asset tracking.

The Pulse-1 is an intelligence-grade GPS tracker built for long-term deployment, persistent monitoring, and mission-critical operations. It is a core component of the AtlasTalon ecosystem and operates exclusively through the Triton-1 Operating System.

This is not a consumer-grade tracking device. It is engineered for deploy-and-forget operations — with intelligent power management that keeps the tracker alive for years while activating instantly when movement is detected or boundaries are crossed.

02 — Capabilities

Always watching. Never wasteful.

01
Live Mode tracking
Real-time location updates at user-defined frequencies from 1 second to 34 hours. Full operator control over the update cadence.
02
Auto-sleep power system
When the map is closed, the tracker drops to a low-power state with periodic 34-hour heartbeats. Battery lasts years, not weeks.
03
Stop detection
When motion ceases, the tracker transmits one final location with exact stop coordinates, then enters deep sleep until movement resumes.
04
Motion wake-up
An onboard accelerometer wakes the tracker the instant the asset moves. No manual intervention, no polling delay.
05
Geofence override
Always-active geofence monitoring that operates even in deep sleep. Breaches trigger instant alerts that override every current setting.
06
Remote command control
Change frequencies, switch modes, modify geofences, request immediate location pings, or shut down the device permanently — all remotely.
03 — Operational Modes

Intelligent state machine.

The tracker adapts to what you're doing — high-frequency updates when you need them, years of standby when you don't.

MODE · 01
Live Mode

Active intelligence tracking. The tracker reports at your chosen frequency while you monitor — from 1 second for critical operations to 24 hours for low-draw surveillance.

  • Intervals: 1s · 5s · 10s · 30s · 1m · 1h · 24h
  • Operator-defined custom intervals
  • Activated when the map is opened
MODE · 02
Auto-Sleep Mode

Deploy-and-forget preservation. When the map closes, the tracker silently drops into a low-power state with a 34-hour heartbeat. Years of standby, zero maintenance.

  • Default 34-hour heartbeat
  • Automatic activation on map close
  • Zero unnecessary network activity
MODE · 03
Geofence Override

A security net that never sleeps. Virtual boundaries stored on the device itself monitor position continuously — even in deep sleep — and fire instant alerts the moment they are crossed.

  • Entry, exit, or bidirectional alerts
  • Multiple geofences per device
  • Overrides all current update settings
04 — Ecosystem

Exclusive to the
AtlasTalon ecosystem.

The Pulse-1 cannot be bound to any non-AtlasTalon system. That exclusivity is what makes unauthorized access structurally impossible — not just difficult.

Triton-1 Operating System
Required for binding, configuration, visualization, and control.
AtlasTalon account
Enrolled user with authenticated credentials for access.
Sovereign Data Infrastructure
All tracking data flows through your private AtlasTalon server.
05 — Technical Specifications

Full specifications.

Physical
Dimensions72 × 42 × 14 mm
Weight68 g
CasingAnodized aluminum, sealed electronics bay
Ingress protectionIP68 (water & dust)
Tamper detectionPhysical intrusion triggers alert
Tracking
PositioningGPS · GLONASS · Galileo · BeiDou
Accuracy< 2.5 m CEP (open sky)
Update intervals1s, 5s, 10s, 30s, 1m, 1h, 24h, 34h, custom
Motion sensing3-axis accelerometer, wake-on-move
Stop detectionAutomatic final-position report
Power
Battery typeLi-po, non-removable
Battery life3+ years at 34-hour heartbeat
Live Mode durationUp to 72 hours continuous at 1-minute intervals
ChargingUSB-C, magnetic pogo optional
Deep-sleep draw< 15 µA
Security & ecosystem
Device bindingPermanent cryptographic handshake
Hardware IDUnchangeable, burned at manufacture
Data transmissionEncrypted end-to-end
Required OSTriton-1 (exclusive)
Data ownershipFull — stored on your Sovereign Data Infrastructure
06 — In the Box

Everything you need.

Pulse-1 tracker
Pre-charged, pre-tested, ready for binding.
USB-C to USB-C cable
1-meter shielded cable for Triton-1 binding and charging.
Mounting hardware
Adhesive pad, magnetic mount, and screw-mount bracket.
Quick start card
Binding instructions and activation checklist.
3-year warranty
Full coverage including firmware updates and hardware.
Weatherproof housing
IP68-rated enclosure with tamper detection.
07 — Pricing

Pulse-1

Includes the tracker, mounting hardware, three years of firmware updates, and hardware warranty. Volume pricing available at 10+ units. Requires an active Triton-1 license.

Full access to all operational modes
3-year firmware & security updates
Unlimited geofences per device
Sovereign Data Infrastructure storage included
PER UNIT
$449/ UNIT
VOLUME DISCOUNTS · ENTERPRISE AGREEMENTS · TRITON-1 REQUIRED
Request Quote
08 — Briefing

Common inquiries.

Yes. The Pulse-1 is exclusive to the AtlasTalon ecosystem and requires Triton-1 for binding, configuration, and control. It cannot be paired with any non-AtlasTalon system, which is what makes unauthorized access impossible.
Over three years at the default 34-hour heartbeat interval. In continuous Live Mode at 1-minute updates, the tracker runs for approximately 72 hours on a single charge. The intelligent state machine transitions between these extremes automatically.
Yes. The Pulse-1 supports GPS, GLONASS, Galileo, and BeiDou constellations simultaneously, giving global coverage with sub-2.5-meter accuracy in open-sky conditions.
Two things. First, the geofence system fires an instant alert the moment the device crosses a boundary — even in deep sleep. Second, you can trigger a remote shutdown from Triton-1, which permanently deactivates the device, removes it from your account, and terminates all connection with no path back to the system.
Yes. There is no limit to the number of trackers per AtlasTalon account. Each device has a unique permanent hardware ID and is managed independently through the Triton-1 GPS application.
